Aluminum Alloy High Speed ​​Automatic Parking Lot Barrier For Parking Management System

1 Set
MOQ
Aluminum Alloy High Speed ​​Automatic Parking Lot Barrier For Parking Management System
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Model Number: SXK-D01
Product name: High Speed Automatic Car Park Barrier for Parking Management System
Color: Silver&Grey
Lift Time: 1s
Arm Length: 3m
Arm Dimension: 3*0.07*0.05m
Arm Type: Straight
Arm Material: Aluminum Alloy
Anti-collision: Optional
Material: Galvanized Plate
Voltage: 220V/110V
Informazioni di base
Model Number: SXK-D01
Termini di pagamento e spedizione
Packaging Details: Standard Export Carton
Supply Ability: 1000 Set/Sets per Month
Descrizione di prodotto
Product Description

High Speed Automatic Car Park Barrier for Parking Management System

SXK-D01 barrier gate uses the international newest technical design and manufactured with precision machine tool. The automatic and intelligent barrier gate is suitable for vehicle flux control of the access in private or public car parks, in residential areas or in highly traffic areas.

Features&Specs
1. Elegant design, state-of-art workmanship and LED arrow sign indicator.
2. Galvanized, electrostatic powder coated for protection against corrosion
3. Maintenance free torque motor, no need frictional clutches
4. Torque motor with a lever drive system that rids the barrier of any belts or pulleys.
5. Counterbalanced via compression spring, avoid accidents caused by tension spring
6. Machine core can automatically warming when outside temperature is below 0
7. Auto reverse at any time if hit an obstacle
8. Lutch key can be unlocked to the clutch when power off, rise arm without removing the top cover
9. Motor cooling fan for heat-protection
10. Multiple protection mechanism: photoelectric limit and motor sensor memory limit, loop detector, air pressure wave switch and infrared photocell, etc to ensure the barrier gate operate accurately and safely
Supply Voltage
Motor Rated Power
Moter Rated Speed
Work Temp.
AC220V/110V
120W
680RPM
-30℃~+75℃
Housing Dim.
Weight
Protection Degree
Life Time
1030*320*330 (mm)
60KG
IP55
5 million
Technology


The Drive Unit-AC MOTOR

Designed for alternating current, does not require limit switches nor a friction clutch and maintenance-free.

Motor cooling fan, solving the problem of heat-protection.



Compressed Balancing Spring

The barrier gate arm weight is counter-balanced via a precisely adjusted compression spring, avoid accidents caused by tension spring.



Librate Cushion Rubber

Absorb vibration during the beam rises and falls, which keeps barrier run smoothly and reduce the impact on mechanism core.

Swing Out

Arm will swing out when hit directly by vehicle (only 1 second model ) to avoid further damage on the vehicle.

Clutch Device

Clutch key can be unlocked to the clutch when power off, conveniently raise the arm without removing the top cover or body housing.

Cases
Our company
Thinkpark was founded in 2006, as an integrated enterprise engaged in designing and manufacturing of access and revenue control systems, including car park barrier gates, car parking systems, LPR/ANPR systems, turnstiles, locker systems and access control products.

Our R&D team has over 10 years experience in this filed. Commitment to development and quality enable us to create the latest innovation of products and perfectly fulfill the customized needs of our customers.

"Only professional, is trustworthy" is the eternal pursuit of Thinkpark group.

Certificates

FAQ

Q: Are you trading company or manufacturer?
A: We are integrated enterprise specialized in R&D and manufacturing
Q: How long of your lead time?
A: 3-15 working days
Q:Can you customize my goods?
A: Yes, we provide with tailored servce upon project requirement.
Q: What's your certificate?
A: ISO9001:2008, ISO9001:14001, CE, Patent license.
